Patent Drawings & Illustration Services

Precision Drafting for Utility, Design, and International Filings

"A picture is worth a thousand words.
A high-quality patent drawing is worth even more."

Located in the Washington, DC area, Artworks IP provides expert illustration support for patent applications. We offer a wide breadth of services including utility drawings, design drawings, trademark drawings, and photo cases.

100% US-Based Security: We do not off-shore or outsource. All work is performed in-house by our US draftsmen to ensure data security and strict compliance with USPTO 37 CFR § 1.84 standards.

Utility Drawings

Formal utility drawings (black & white line art) that define the functional aspects of an invention. We ensure all margins, line weights, and shading adhere to USPTO requirements to avoid Office Action rejections.

Design Patent Drawings

Design patents protect the ornamental appearance of a product. Our draftsmen are experts in surface shading and contouring to clearly define the scope of the claim as required by the examiner.

International Filing (PCT/EPO)

Filing globally? We format drawings to meet WIPO (PCT) and EPO standards. Simultaneously seek protection in the US, Europe, China, and Korea with a single set of compliant drawings.

Trademark & Trade Dress

We create clear "Standard Character" and "Special Form" drawings for trademark submission. Ensure your mark is recorded accurately in the USPTO database to put competitors on notice.

Take a look at our other services including technical illustrations, 3D renderings, trial graphic services, and patent drafting & filing.
